ultrasonic Ultraprobe 2000

The ultrasonic Ultraprobe 2000 is a sophisticated diagnostic instrument that bridges the gap between basic leak detectors and complex digital analyzers. Its primary advantage is the ability to tune the frequency (from 20 kHz to 100 kHz), which allows the operator to filter out background noise and focus precisely on the ultrasonic emission of interest. This “tuning” capability is essential for diagnosing complex issues, such as differentiating between a healthy steam trap and one that is failing in a “blow-through” condition, or identifying the exact stage of bearing degradation based on the intensity of the ultrasonic signal.The device features an analog meter that responds instantly to changes in ultrasonic intensity, providing a tactile and intuitive experience for the operator. In electrical inspections, the Ultraprobe 2000 is invaluable for identifying early-stage corona and arcing in high-voltage equipment, often long before thermal cameras can detect a temperature rise. For mechanical condition monitoring, the system can be integrated with data loggers to track the health of slow-speed bearings, where traditional vibration analysis often struggles. The Ultraprobe 2000 is built for the professional who needs a reliable, highly sensitive, and versatile tool for a wide range of NDT (non-destructive testing) applications, from finding the smallest vacuum leak to preventing a multi-million dollar electrical failure.
